功率輸出(所有聲道):
220 W/Ch(6 ohms, 1 kHz, 10% THD,1-ch driven)
100 W/Ch (8 ohms, 20 Hz–20 kHz, 0.08% THD, 2-ch driven, FTC)
動態功率:
250 W (3 ohms, Front)
220 W (4 ohms, Front)
130 W (8 ohms, Front)
THD+N(總諧波失真 + 噪聲):0.08% (20 Hz–20 kHz, half power)
輸入靈敏度和阻抗:
200 mV rms/47 k-ohms (Line)
3.5 mV rms/47 k-ohms (Phono MM)
額定 RCA 輸出電平和阻抗:
1 V rms/470 ohms (Subwoofer pre-out)
200 mV rms/470 ohms
(Zone 2/Zone B line-out)
頻率響應:10 Hz–100 kHz/+1 dB, -3 dB (Direct/Pure Audio)
音調控制:
±10 dB, 20 Hz (低音)
±10 dB, 20 kHz (高音)
信噪比:
106 dB (Line, IHF-A)
80 dB (Phono, IHF-A)
揚聲器阻抗:4–16 ohms
輸入靈敏度/輸出電平和阻抗:
1.0 Vp–p/75 ohms (Component Y)
0.7 Vp–p/75 ohms (Component Pb/Pr)
1.0 Vp–p/75 ohms (Composite)
調諧頻率範圍:
FM:87.5 MHz–107.9 MHz
AM:530 kHz–1,710 kHz
電源:AC120 V~, 60 Hz
功耗(運作):750 W
功耗(空閒):75W
功耗(待機):0.1W
